S1138 Multi-Hit Rotary Endform Machine

The S1138 Multi-Hit Hydraulic Endformer  incorporates rapid endforming, grooving, and cutting operations in one machine.
Combining key design features of other Strategic Automation Machine products with new, patented technology enables the S1138 to achieve a new performance standard in tube forming.

The Strategic Automation S1138 utilizes an 8-station rotationally indexing turret, which incorporates up to 8 individual sets of clamp tooling.
Station 1 is a load position, stations 2 through 7 are “work” stations, and station 8 is an unload station.

The result of this manufacturing process is a complete, finished part, with up to 6 endform operations, without excessive diameter reduction, in 4 – 5 seconds.
